Mini digital control multi-function screw pump hot runner air over oil cylinder precise injection machine

LPMS 6000DH

Mini digital control multi-function screw pump hot runner air over oil cylinder precise injection machine

Adopts high precision screw cylinder and hot runner system. High precision injection volume. Lower material cost.
All the molding parameters are monitored, protected and controlled to ensure molding quality.
Multiple injection zones with different injection time&pressure, different holding time&pressure, different volume is optional.
temperature zones for screw cylinder. Injection nozzle and hot runner system temperature can be controlled independently.
Injection servo system is intelligent controlled. Injection speed and torque are adjustable to ensure high precision molding.
Compact design saves space and lower mold set cost.
Over-temperature alarm and automatically cut off the heating power.
Safety light curtain and two palm buttons to protect operator during the operation.
Ejection system is included. Auto-feeding system and dryer system are optional.

Application

The machine is engineered for small part molding. The precise screw pump ensures the precise injection volume. Servo system and 24 bit high precision absolute encoder ensures injection high reliability and high repetition accuracy.

Applications including : all types of micro parts high precision molding.

Specification

Machine Size / Weight	960 mm x 1730 mm x 2015 mm / 540 kg
Working Station Height	1000 mm
Injection system & Q'ty	Screw pump
Screw diameter	16 mm
Screw max speed	500 Rev / min
Torque	0~21.5 N.M
Injection Stroke	70 mm
Injection Volume	14 cm³
Injection Pressure	0-63 MPa
Injection speed	500 mm / s
Injection type	Hot runner system
Clamping	Air Over Oil Cylinder
Clamping Force / Stroke	5T / 150 mm
Ejection	Air cylinder
Ejection force / stock	100 N / 10MM
Electricity ¹	AC200-240 VAC/1 Phase/50 Hz
Max .Power	6 Kw
Servo Power	1.5 kw
Temperature Range	Ambient up to 250°C / 485°F
Min. Air Pressure	5 Bar
Control System	PLC+7”HMI
Auto Feeding System	Optional
Safety Device	Light curtain and 2 palm buttons
Mold Set Size	250 mm x 150 mm x 308mm
Max . Mold Set Size	300 mm x 200 mm x 308 mm
